Foil Retort Pouches

Retort Canning Bags

Retort Canning Bags Haide / Color Leader are Retort Canning Bags expert, our advantage as, Strong sealing and leakage-proof as priority of every retorted flexible packaging. 121, 125, 135 Centigrade sterilization with pressure condition, compatible for custom retort pot maximum sterilizing 60...

Retort Canning Bags


Haide / Color Leader are Retort Canning Bags expert, our advantage as,

 ● Strong sealing and leakage-proof as priority of every retorted flexible packaging.

 ● 121, 125, 135 Centigrade sterilization with pressure condition, compatible for custom retort pot maximum sterilizing 60 mins.

 ● 2-3 years shelf life and safe usage.

 ● Foil doy pouch with high barrier transparent bottom gusset or transparent window application available

 ● Aluminum Foil 4-5 layers structure or Transparent plastic high barrier 3 layers material up to 2 years shelf life technology.

 ● Anti-pin hole function by both clear barrier filming lamination or barrier adhesive technique.

 ● Pre-formed Pouches or In-line Formed retort able Roll Stock


Introduction:

The retort canning pouches are a flexible laminated packaging that can withstand thermal processing. It has the advantage of offering the shelf stability like metal cans, coupled with the nutrient value associated with frozen foods. The retort canning bags have been considered the most significant milestone in food packaging since the metal can achieved, and has the potential to become a feasible alternative to the metal can and glassware.


Advantages compared to metal can,

 ● Flexible pouches are more economy to distribute and therefore have lower logistic costs and require less disposal space.

 ● Storage space for empty flexible pouches is also reduced.

 ● The thinner material structure permits a reduced sterilizing time and faster transfer to its critical point and thus less of a chance to overheat the product while producing better layout.

 ● Offers higher quality together with better retention of the heat-sensitive nutrients.

 ● The thermal process is complex and experienced data measuring due to the number of critical processing parameters which must be monitored (e.g., gram weight, residual air, pouch layers and RCPP thickness, steam/air mixture).

 ● Artwork designed can be printed into the laminate permanently.


Characteristics essential to a satisfactory retort canning pouch are:

 ● Low oxygen permeability

 ● Low moisture permeability

 ● Resistant to penetration by fats, oils and other food components

 ● Physical strength to resist physical abuse (i.e., tearing, pin-holing, fatigue, impact and abrasion) during packing, retorting, storage and logistic

 ● Absence of solvent residues.

 ● Bonding materials for the laminates migration level must be within regulation.


Clear High Barrier Lamination:

We introduced the Japanese clear high barrier film since the year 2002 which technology brings food packaging more options for long shelf life, transparent retort available, microwavable pouches to replace foil pouch in food packaging solutions.


Clear High Barrier Material Selection:


Structure Name

Barrier Coating

OTR (cc/100in2/ 24 hrs)

MVTR (g/100in2/ 24 hrs)

Cost (10 to 1)

PET-C

Aluminum Oxide (AlOx)

0.1

0.1

10

PET-C (retort)

Aluminum Oxide (AlOx)

0.3

0.4

10

PA-C (retort)

Aluminum Oxide (AlOx)

0.3

0.8

9

PET-PIR (retort)

Aluminum Oxide (AlOx)

0.4

0.5

9

PET-CS (retort)

Aluminum Oxide (AlOx)

0.6

0.8

8

EVAL

EVOH Sheet

0.8

6-10

9

PET-G

SiOx-coated

3

5

4

PET-P

SiOx-coated

2

20

4

UNI-KPA (Boil)

PVDC-coated

6

6

6

KPA / KPET

PVDC-coated

8-15

40

2


Bacteria Inhibiting film Technology:

Haide Packaging as the leader company in flexible packaging industry who has the patented filming technology of Bacteria Inhibiting filming application on food packaging, large scale applied by industrial clients in form of roll films and custom pouches, and dramatically changing the sterilization method of retort, boil or pasteurization with reliable supplement that certain content can be boiled with this technology to substitute retort, making a much easier retort pouch while keep better taste and flavour.


Application:

Haide / Color Leader retort pouch or roll stock is suitable for canned retort food likes Canned Fish, canned Sea food, canned meat, Sauce meal, Soup, Vegetable, Fruit can/cup, Ready-made meal, Pet snack, Military, Prison food, Church & Charity’s Succour, Space meal, etc.


Type and other names

Retort Canning Pouches/ Retort Canning Bags / Canned food retort pouch / Foil canning Pouch / Foil canned food packaging

Standard and certification

BRC Packaging, GB/T10004-2008, GB9685-2016, FSSC22000/ISO22000:2015, ISO9001:2015, FDA/FCS/USDA/CFIA

Multi-layer lamination

Aluminum Foil Retort

4 layers: (matte ink) PET, ink, Alu, PA and RCPP 121/135C

5 layers: (matte ink) PET, ink, PA, Alu, PA and RCPP 121/135C

Transparent short shelf life

3 layers: (matte ink) PET, ink, PA and RCPP 121/135C

Transparent Retort High Barrier

3 layers: (matte ink) PA, ink, Barrier PET/PA and RCPP 121/135C

       (matte ink) Barrier PET/PA, ink, PA and RCPP 121/135C

Oxygen Barrier

Foil Oxgen Barrier (OTR) <0.005 cc/m2/24hrs

Transparent Oxygen barrier (OTR)  <0.1, <1, <2, <4, <6cc/m2/24hrs

Moisture Barrier

Foil Moisture Barrier (WVTR) <0.005 g/m3/24hrs

Transparent Moisture barriers (WVTR) <0.1g/m3, <0.4g/m3, <1.0g/m3, <2.0g/m3, <4.0g/m3/24hrs

Other Application

Variety of finished likes matte, Gloss, Varnish, Registered matte and gloss finished printed, Registered matte and gloss finished printed, tear notch, handle, hanging hole, laser scoring
